SENKING Continuous Batch Washer P90-11 & centrifugal extractor

Goudkuil number: 000452
Manufacturer: Jensen/Senking
Model: P90-11 & Z1400HG

SENKING Continuous Batch Washer P90-11
In Universal version
•   Washing process in standing baths for high flexibility
•   Drum design according to the archimedean principle for full use of the drum volume
•   with eccentric, wash board-shaped helix – Senking patent – provides excellent mechanical action
•   a combined single/double drum version
•   PLC control, PC-assisted for visualisation with integrated
Bus System for all components

Technical details
Number of compartments: 11 pcs
Loading capacity: 90 kg comp.
Hourly output at 30 minutes washtime 1980 kg/h
•      Nominal load, batch size:
– max. 10% overload
•     depending on the type of linen and on the washing procedure

SENKING CENTRIFUGAL EXTRACTOR Z1400
High -capacity centrifugal extractor for installation
Behind continuous batch washers

•   only two drum positions for loading/extraction and unloading for short cycle times
•   large loading door for easy and fast loading
•   large drum depth and large drum diameter
to achieve a flat linen cake for very low moisture retention values
•   large perforated drum surface for lowest moisture retention
•   with multiple parallel systems for unbalance equalizing

Technical data
batch size: 100 kg
minimum cycle time:
polyester/cotton: 2,5 min
cotton: 3 min
